Nissan / Nismo

Nismo Double Valve Springs to suit Datsun B110 B210 B310 A12 A14 A15 13203-H2300

Nismo Double Valve Springs to suit Datsun B110 B210 B310 A12 A14 A15 13203-H2300

Regular price $485.00 AUD
Regular price Sale price $485.00 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.

Low stock: 1 left

Genuine Nissan / Nismo Double Valve Springs to suit Datsun B110 B210 B310 A12 A14 A15

Brand new

Application vehicles.

  • Datsun 1200 (7001 - 7305)
  • Datsun 1200 Ute (7510 - 9403)
  • Datsun 1000 (6604 - 7001)
  • Datsun 1000 Ute (6604 - 7001)
  • Datsun 120Y, B210 (7305 - 7710)
  • Datsun 120Y/140Y, B310 (7305 - 8304)
  • Datsun E10 Cherry (7010 - 7409)
  • Datsun C120 Vanette (7810 - 8811)
  • Datsun C22 Vanette (8509 - 9403)

Available fit to A-Series Engine.(A10/A12/A14/A15)

Include.

  • 8 x Outer springs. (Nissan)
  • 8 x Inner springs. (Nismo)



The double valve springs control Valve Surging at the time of high rpms.

It supports; cam lift - 6.5mm, valve lift - 9.4mm.

  • *Lower the blue paint points.
  • *Change the spring seats and spring retainers together for double valve springs.

Nismo Recommendation : please use together genuine valve parts below,

  1. Spring seats: 13205-H2300
  2. Spring retainers: 13209-H2302

*SIZE(Approx)

  • Coil diameter: 2.8mm.
  • Coil OD: 21mm.
  • Free Length: 41.2mm.
  • Set Length: 34mm.
  • Lift Length: 24mm.
  • Set Load: 12.5Kgf(123N)
  • Lift Load: 29.9Kgf.(294N)
  • Supported Valve Lift: 9.4mm(If Cam Lift: 6.5mm)
  • ((1in = 25.4mm))
